Cold Drawn and Hot Rolled Stainless Steel Flat Bars: ASTM A276/A484M

Flat bar

Product

Stainless Steel Flat Bar

Product Description of Stainless Steel Flat Bar

At YES Stainless International, we specialize in providing high-quality stainless steel flat bars that meet the industrial standards of ASTM A276. Designed for durability, precision, and versatility, our stainless steel flat bars are the ideal choice for a wide range of industrial, construction, and manufacturing applications. Whether you need hot-rolled or cold-drawn flat bars, our products are engineered to deliver exceptional performance and reliability. Partner with YES Stainless International for your stainless steel flat bar needs and enjoy unmatched quality and service delivered worldwide.

Product Overview of Stainless Steel Flat Bar

Types	International Standard	Dimension	Stainless Steel Grade	Surface Finishes
Cold Drawn	ASTM A276 ASTM A484M	Thickness: 3-30mm Width: 25-130mm	304(L), 316L	Bright, Hairline
Hot Drawn	ASTM A276 ASTM A484M	Thickness: 3-12mm Width: 25-120mm	304(L), 316L	Pickling

Key Features of Stainless Steel Flat Bar:

Corrosion Resistance:Made from high-quality stainless steel grades like 304 and 316, flat bars are resistant to rust, oxidation, and chemical exposure, making them suitable for harsh environments, including marine and industrial settings.

Versatile Fabrication Options:Stainless steel flat bars can be easily cut, welded, drilled, and machined, allowing them to be tailored for various applications such as construction, machinery, and decorative projects.

➣ Cold Drawn

➣ Hot Rolled

Product Specification of cold-drawn stainless steel flat bar

Cold Draw Flat Bar
Thickness (mm)	Width (mm)
3	25	30	35	40	45	50
4	25	30	35	40	45	50	55	60	65
5	25	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100
6	25	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100
8	25	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100
10	25	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100
12	25	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100
14	25	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100
16	25	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100
18	40	45	50	55	60	65	70	75	80	85	90	95	100	105	110	115	120	125	130
20	40	45	50	55	60	65	70	75	80	85	90	95	100	105	110	115	120	125	130
22	40	45	50	55	60	65	70	75	80	85	90	95	100	105	110	115	120	125	130
24	45	50	55	60	65	70	75	80	85	90	95	100	105	110	115	120	125	130
26	50	55	60	65	70	75	80	85	90	95	100	105	110	115	120	125	130
30	50	55	60	65	70	75	80	85	90	95	100	105	110	115	120	125	130

Width (mm)	Widthness Tolerance(mm)
1.5 - 9.5	± 0.12	± 0.12
9.5 - 25	± 0.10	± 0.10
25 - 50	± 0.15	± 0.10
50 - 75	± 0.20	± 0.10
75 - 115	± 0.25	± 0.13

Thickness (mm)	Thickness Tolerance(mm)
< 0.70	± 0.03
0.70 - 1.00	± 0.04
1.00 - 25.00	± 0.05
25.00 - 50.00	± 0.08

➣ Cold Drawn

➣ Hot Rolled

Product Specification of hot rolled stainless steel flat bar

Hot Draw Flat Bar
Thickness (mm)	Width (mm)
3	25	30	35	40	45	50
4	25	30	35	40	45	50	55	60	65	70
5	25	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100
6	25	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100	105	110	115	120
8	25	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100	105	110	115	120
10	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100	105	110	115	120
12	30	35	40	45	50	55	60	65	70	75	80	85	90	95	100	105	110	115	120

Width(mm)	Thickness Tolerance(mm)			Width (mm)
Width(mm)	3.2-13	13-25	25-50	Width (mm)
<25	± 0.20	± 0.25	-	± 0.40
25 - 50	± 0.30	± 0.40	± 0.80	± 0.80
50-100	± 0.40	± 0.50	± 0.80	+1.60 -0.8
100-150	± 0.40	± 0.50	± 0.80	+2.40 -1.60
