【ASTM A312 Indsutrial Pipe】
Product Description of ASTM A312 Stainless Steel Pipe
Explore our ASTM A312 Welded Stainless Steel Pipe, engineered for exceptional durability and reliability in industrial applications. YES Stainless is your trusted supplier of high-quality welded stainless steel pipes, crafted to meet rigorous ASTM A312 standards.
Product Overview of A312 Seamless Stainless Steel Pipes :
| International Standard | Dimension | Stainless Steel Grade |
| ASTM A312/A312M, ASME SA312/SA312M ASME B36.19MASME B36.10M | OD: 13.7~762.0mm WT: 1.65~12.7mm | TP304, TP304L, TP304H, TP310, TP310S, TP316, TP316L, TP316Ti, TP317, TP317L, TP321, TP321H |
Key Features of ASTM A312 Stainless Steel Pipe :
- High-Quality Stainless Steel: Constructed from premium stainless steel, our ASTM A312 welded pipes offer superior corrosion resistance, ensuring longevity and reliability in challenging environments.
- Precision Manufacturing: Each pipe is meticulously crafted with precise dimensions and tight tolerances, guaranteeing consistency and reliability in every application.
- Versatile Industrial Use: Ideal for applications in industries such as oil and gas, chemical processing, water treatment, and more, our ASTM A312 welded stainless steel pipes meet diverse industrial needs.
Product Specification of ASTM A312 Stainless Steel Pipe
| Outside Diameter | Thickness (mm) | ||||||
| DN | inch | mm | SCH 55 | SCH 10S | SCH 40S | STD | SCH 80S |
| 8 | 1⁄4’’ | 13.7 | - | 1.65 | 2.24 | 2.24 | 3.02 |
| 10 | 3⁄8’’ | 17.1 | - | 1.65 | 2.31 | 2.31 | 3.2 |
| 15 | 1⁄2’’ | 21.3 | 1.65 | 2.11 | 2.77 | 2.77 | 3.73 |
| 20 | 3⁄4’’ | 26.7 | 1.65 | 2.11 | 2.87 | 2.24 | 3.91 |
| 25 | 1’’ | 33.4 | 1.65 | 2.77 | 3.38 | 3.38 | 4.55 |
| 32 | 1 1⁄4’’ | 42.2 | 1.65 | 2.77 | 3.56 | 3.56 | 4.85 |
| 40 | 1 1⁄2’’ | 48.3 | 1.65 | 2.77 | 3.68 | 3.68 | 5.08 |
| 50 | 2’’ | 60.3 | 1.65 | 2.77 | 3.91 | 3.91 | 5.54 |
| 65 | 2 1⁄2’’ | 73.0 | 2.11 | 3.05 | 5.16 | 5.16 | 7.01 |
| 80 | 3’’ | 88.9 | 2.11 | 3.05 | 5.49 | 5.49 | 7.62 |
| 90 | 3 1⁄2’’ | 101.6 | 2.11 | 3.05 | 5.74 | 5.74 | 8.08 |
| 100 | 4’’ | 114.3 | 2.11 | 3.05 | 6.02 | 6.02 | 8.56 |
| 125 | 5’’ | 141.3 | 2.77 | 3.40 | 6.55 | 6.55 | 9.53 |
| 150 | 6’’ | 168 | 2.77 | 3.40 | 7.11 | 7.11 | 10.97 |
| 200 | 8’’ | 219.1 | 2.77 | 3.76 | 8.18 | 8.18 | 12.7 |
| 250 | 10’’ | 273.1 | 3.4 | 4.19 | 9.27 | 9.27 | 12.7 |
| 300 | 12’’ | 323.9 | 3.96 | 4.57 | 9.53 | 9.53 | 12.7 |
| 350 | 14’’ | 355.6 | 3.96 | 4.78 | - | 9.53 | - |
| 400 | 16’’ | 406.4 | 4.19 | 4.78 | - | 9.53 | - |
| 450 | 18’’ | 457.2 | 4.19 | 4.78 | - | 9.53 | - |
| 500 | 20’’ | 508 | 4.78 | 5.54 | - | 9.53 | - |
| 550 | 22’’ | 558.8 | 4.78 | 5.54 | - | 9.53 | - |
| 600 | 24’’ | 609.6 | 5.54 | 6.35 | - | 9.53 | - |
| 650 | 26’’ | 660.4 | - | - | - | 9.53 | - |
| 700 | 28’’ | 711.2 | - | - | - | 9.53 | - |
| 750 | 30’’ | 762 | 6.35 | 7.92 | - | 9.53 | - |
